HOBBYMATE Micro Receiver Support PPM SBUS Output - 8CH/18CH Comp

  • Our Price: $12.40

  • SKU: HBS801C


Add to Cart: Tell a friend

HOBBYMATE Micro Receiver Support PPM SBUS Output - 8CH/18CH Compatible with DSM-2 DSM-X Radio Transmitter
11

Compatible with DSSS 2.4G DSM-2 / DSM-X protocol,DX6i, DX7, DX8 ......
With SBUS + PPM function, and can be used at the same time, no external welding processing
Micro Size, Light Weight - 10*16mm,0.6g weeight, well fit outdoor, indoor, and FPV mini Drone, such as 110 100 90 80mm drone.
Dedicated high gain antenna, with high gain amplifier eable a better control range and more stability
Distance: Far Reach Range up to 1500 Meters



Specification:
Article Name: S801C
Channels: 8CH PPM, S-BUS 18CH
Model type: Multi-rotor Helicopter Airplane
Frequency range: 2,403-2,479 GHz
Band width: 500-876 KHz
RX Sensitivity: -108 dBm
Modulation type: GFSK
DSC port: PPM / S. Bus
Transfer method: DSSS
Input Power Supply: 4.0-9 V
Working current: 60 mA
Frame rate: 11/22ms
Display Method: LED
No ground interference: 1500 m
Working current: 60mA
Each data channel: depend on the transmitter
Antenna Length: 14.5 cm (5.7 in)
Size: 10 * 16 cm (3.93 - 6.3 in)


How to bind:
1.Press the code switch of the receiver until the red led flash fastly, then release it.
2.Turn on the transmitter
3.The receiver will flash slowly,the binding success when it does not flash,and always light.

23S801C-1
Advantage:
Product characteristics and superiority compared to other DSM-2 DSM-X Receiver
1) Dedicated high gain antenna, with high gain amplifier, stable, far away. (Distance from the same type of distance)
2) with SBUS + PPM function, and can be used at the same time, no external welding processing.
3) Compatible with DSSS 2.4G DSM-2 / DSM-X protocol
4) ultra light weight, ultra-extreme to receive distance, high sensitivity reception
5) to improve the anti-interference capability
6) Failsafe Function


Package Including
1 * S801C 8CH Mini Receiver
